From README:
PathFinder searches for “signatures” within graphs. Graphs being searched are directed and cyclic. Many, but not all nodes within the graph have labels. Any given node may have more than one label, and any label may be applied to more than one node. A signature is an orderd list of labels. PathFinder searches for paths between labels within the signature. PathFinder returns success if there is a path from a node with the first label in the signature that passes through nodes with each label in order, ultimately reaching a node with the last label in the signature. Labeled nodes need not be contiguous on any given path.
Problem Configuration
./PathFinder.x -x <data file>
Sample data sets are included in the generatedData and scaleData subdirectories. The scaleData files are intended for performance characterization.
Analysis
Build and Run Information
Compiler = 'clang 5.0.1'
Build_Flags = '-g -O3 -march=native -fopenmp -lgomp -lm'
Run_Parameters = '-x data/scaleData/4kx750.adj_list'
Scaling
Program Aggregate
| 1 (100.0%) | 1.6 | 6.1% | 63.3% | 0.0% | 0.49 | 14.5% | 12.3% | 0.0% |
| 72 (100.0%) | 1.3 | 5.6% | 61.9% | 0.0% | 0.42 | 22.4% | 19.3% | 0.0% |
findNextLabel
| 1 (69.9%) | 1.6 | 5.5% | 68.0% | 0.0% | 0.52 | 13.8% | 12.5% | 0.0% |
| 72 (40.8%) | 2.0 | 6.0% | 66.6% | 0.0% | 0.63 | 37.6% | 34.7% | 0.0% |
138 bool findNextLabel( Node *node, Signature labels, NodePtrVec *result, Bitfield *visited )
139 {
140 EdgeList *edge;
141 bool success = false;
142 NodePtrVec *nextLegResult = NULL;
143 /* NodePtrVec *nextLegVisited = NULL; */
144 Bitfield *nextLegVisited = NULL;
145
146
147 /* A little basic error checking */
148 if ( !node || !labels || !result|| !visited )
149 {
150 return( false );
151 }
152
153 /* If this node is already in the vector, we have found a loop. return false. */
154
155 if ( Bitfield_nodeVisited( visited, node ) )
156 return( false );
157
158 /* put this node on the result vector to show that we've been here */
159 NodePtrVec_push( result, node );
160
161 /* Check this node's edges to see if there's a match */
162 /* Note: We have a NodePtrVec holding the set of nodes with this label. It
163 * may be more optimal to see if a given edge node is in that set
164 * rather than doing a bunch of inefficient strcmp calls. Another approach
165 * would be to have unique hash values for each label, and thereby be
166 * able to compare those. However for the initial version of this code,
167 * keeping things simple and straightforward, we're doing the string
168 * compare.
169 */
170
| 1 (32.3%) | 1.3 | 8.1% | 68.0% | 0.0% | 0.40 | 17.3% | 15.7% | 0.0% |
| 72 (18.0%) | 1.6 | 8.7% | 66.7% | 0.0% | 0.48 | 46.7% | 43.2% | 0.0% |
171 for ( edge = node->edges; edge != NULL; edge = edge->nextEdge )
172 {
173
174 // string based:
175 if ( edge->targetNode->label
&& strcmp( edge->targetNode->label, labels[0] ) == 0 )
176 // index based: if ( edge->targetNode->labelIdx == labelIdxs[0] )
177 {
178 if ( labels[1] != NULL ) /* more steps in the signature */
179 {
180 nextLegResult = NodePtrVec_new( 50 ); /* arbitrary size,
malloc success checked in recursion */
181 nextLegVisited = Bitfield_new(visited->bitsNeeded);
182
183 success = findNextLabel( edge->targetNode, &labels[1],
nextLegResult, nextLegVisited );
184 /* NodePtrVec_delete( nextLegVisited ); */
185 Bitfield_delete( nextLegVisited );
186 if ( success )
187 {
188 NodePtrVec_appendVectors( result, nextLegResult, true );
189 NodePtrVec_delete( nextLegResult );
190 return( true );
191 }
192
193 }
194 else /* We have exhausted the signature - ultimate victory! */
195 {
196 /* Register this edge node as being the final node */
197 NodePtrVec_push( result, edge->targetNode );
198 return( true );
199 }
200 }
201 }
202
203
204 /* IF we made it here, we need to continue through the tree, seeing if any of our
205 * edge nodes have a connection to a labeled node.
206 */
207 for ( edge = node->edges; edge != NULL; edge = edge->nextEdge )
208 {
209 success = findNextLabel( edge->targetNode, labels, result, visited );
210 if ( success )
211 return( true ); /* this edge has a path to the ultimate signature path */
212 }
213
214
215 /* and, if we make it here, we have failed. */
216 NodePtrVec_pop( result ); /* take current node off the result vector */
217 return false;
218 }
